Drawing
Parameter
| Boundary dimensions |
| d | 35 |
| D | 72 |
| B | 17 |
| r Min | 1.1 |
| r 1 (Min) | 0.6 |
| Rated load (N) |
| Cr | 29700 |
| Cor | 20100 |
| Rated load {kgf} |
| Cr | 3050 |
| Cor | 2050 |
| Speed ratings(1)(rpm) |
| Grease | 10000 |
| Oil | 14000 |
| Fitting dimensions (mm) |
| d a (Min) | 42 |
| Da (Max) | 65 |
| r a (Max) | 1 |
| Bearing No.(2) |
| Single row | 7207A |
| DB | 7207DB |
| DF | 7207DF |
| DT | 7207DT |
| Rated load(Duplex type) (N) |
| Cr | 48500 |
| Cor | 40000 |
| Rated load(Duplex type) {kgf} |
| Cr | 4900 |
| Cor | 4100 |
| Duplex type Speed ratings rpm(1) (rpm) |
| Grease | 8500 |
| Oil | 12000 |
| Duplex type Function Point distance(mm) a0(mm) |
| back-to-back | 47.9 |
| Face-to-face | 13.9 |
| Duplex type Fitting dimensions mm |
| d b (3) (Min) | 40 |
| Db (Max) | 67 |
| r b (3) (Max) | 0.6 |
Details
Wuxi Bosu Transmission Equipment Co., Ltd.specializes in selling NSK-7207DB-Angular Contact Ball Bearing，Relevant information of NSK-7207DB-Angular Contact Ball Bearing includes： Designation: 7207DB d:35 D:72 B:17 Brand:NSK Type:Angular Contact Ball Bearing ，Want to know more about NSK-7207DB-Angular Contact Ball Bearing You can consult online or call the hotline, we will provide you with detailed service.
NSK-7207DB-Angular Contact Ball Bearing is widely used.NSK-7207DB-Angular Contact Ball Bearing is mainly used in construction machinery, machine tools, automobiles, metallurgy, mines, petroleum, machinery, electric power, railways and other industries. The price of NSK-7207DB-Angular Contact Ball Bearing sold by the company is reasonable, the quality is guaranteed, the service in all aspects is provided, and the customer's demand is satisfied.
